Chapter 1 Names of Parts and Their Functions
3
1.1 System Configuration and Names of Components (Continued)
The names (generic names) of components of the microscope and the corresponding product names and
model numbers are shown in the following table.
In this manual, generic names are used to provide a general description of each device, and product names
and model numbers are used to provide product-specific descriptions.
Component name (generic) Product Model
Main body Inverted Research Microscope ECLIPSE Ti2-U ECLIPSE Ti2-U
Tube ER tube TC-T-ER
Tube base unit Eyepiece tube base unit with port TI2-T-BC
Eyepiece Eyepiece CFI 10X
Manual stage Stage TC-S-SR
Stage handle Long handle TI2-S-HL
Stage holder Ring holder set C-S-HLS
Nosepiece DIC sextuple nosepiece TI2-N-ND
Objective CFI objective
Port Direct C mount adapter
Diascopic illumination lamphouse Diascopic LED lamphouse TI2-D-LHLED
Pillar for dia illumination Pillar for dia illumination TI2-D-PD
Condenser
Condenser turret TC-C-TC
LWD condenser lens TI-C-LWD
Polarizer DIC polarizer TI2-C-DICP
Analyzer slider Analyzer TI2-C-DICA
FL turret Intelligent epi filter turret TI2-F-FLT-I
Epi-fluorescence attachment
Fixed main branch TI2-LA-BF
EPI-FL module TI2-LA-FL-2
Episcopic field diaphragm slider Circular field stop slider TI2-F-FSC
Light source for episcopic
illumination
Fluorescence LED illumination system D-LEDI
Note: For details on how to use the units containing devices other than the above, see “Chapter 3 Usage of
Components.”
