Network QoS Policies
200
Quality of Service Guide
3HE 11014 AAAC TQZZA Edition: 01
4.4.2.3 Show Commands
dscp-table
Syntax dscp-table [value dscp-value]
Context show>qos
Description This command displays DSCP name to DSCP value mappings.
Parameters value dscp-value — the specific DSCP value for which to display information
Values 0 to 63
Default show all values
Output The following output is an example of DSCP name to DSCP value mappings information, and
Table 33 describes the fields.
Output Example
*A:ALU-1# show qos dscp-table
===========================================================
DSCP Mapping
===========================================================
DSCP Name DSCP Value TOS (bin) TOS (hex)
-----------------------------------------------------------
be 0 0000 0000 00
cp1 1 0000 0100 04
cp2 2 0000 1000 08
cp3 3 0000 1100 0C
cp4 4 0001 0000 10
cp5 5 0001 0100 14
cp6 6 0001 1000 18
cp7 7 0001 1100 1C
cs1 8 0010 0000 20
cp9 9 0010 0100 24
af11 10 0010 1000 28
cp11 11 0010 1100 2C
af12 12 0011 0000 30
cp13 13 0011 0100 34
af13 14 0011 1000 38
cp15 15 0011 1100 3C
cs2 16 0100 0000 40
cp17 17 0100 0100 44
af21 18 0100 1000 48
cp19 19 0100 1100 4C
af22 20 0101 0000 50
cp21 21 0101 0100 54
Note: The following command outputs are examples only; actual displays may differ
depending on supported functionality and user configuration.
