Quality of Service Guide QoS Fabric Profiles
Edition: 01 3HE 11014 AAAC TQZZA 429
qos
Syntax qos
Context show>system
Description This command displays system QoS information for the 7705 SAR-A, 7705 SAR-Ax,
7705 SAR-H, 7705 SAR-Hc, 7705 SAR-M, 7705 SAR-W, and 7705 SAR-Wx.
This command is not supported on the 7705 SAR-X.
Output The following output is an example of system QoS information, and Table 64 describes the
fields.
Output Example
*A:ALU-1>show>system# qos
========================================================================
System QOS Configuration
========================================================================
Access Ingress Aggregate Rate : 1234 Kbps
Access Ingress Unshaped Sap CIR : 123 Kbps
Network Ingress Aggregate Rate : 456 Kbps
========================================================================
*A:ALU-1>show>system# qos
Table 63 QoS Fabric Profile Command Output
Label Description
Policy-id The fabric profile QoS policy number
Mode The fabric profile mode, either aggregate or destination
Description The description associated with the fabric profile
Aggregate-rate The rate of the fabric shapers in aggregate mode, in kb/s
Unshaped-sap-cir The CIR rate of the aggregate SAP shaper for all
unshaped 4-priority SAPs, in kb/s
Destination MDA/Rate (Kbps) The slot/mda number of the destination adapter card,
and the rate of the fabric shapers in per-destination
mode, in kb/s
Associations The adapter cards to which the specified fabric profile is
assigned and in which direction, that is, network ingress
to fabric or access ingress to fabric
