QoS and QoS Policies
96
Quality of Service Guide
3HE 11014 AAAC TQZZA Edition: 01
Table 10 Scheduling Modes Supported by Adapter Cards and Ports at Network Egress
Adapter Card or Port Profiled 4-Priority 16-Priority
8-port Ethernet Adapter cards, versions 1 and 2 on the 7705 SAR-8 and
version 2 on the 7705 SAR-18
✓✓
8-port Gigabit Ethernet Adapter card ✓
Packet Microwave Adapter card ✓
2-port 10GigE (Ethernet) Adapter card/module ✓
6-port Ethernet 10Gbps Adapter card
✓
1
10-port 1GigE/1-port 10GigE X-Adapter card ✓
4-port SAR-H Fast Ethernet module ✓
6-port SAR-M Ethernet module ✓
Ethernet ports on the 7705 SAR-A (both variants) ✓
Ethernet ports on the 7705 SAR-Ax ✓
Ethernet ports on the 7705 SAR-H ✓
Ethernet ports on the 7705 SAR-Hc ✓
Ethernet ports on the 7705 SAR-M (all variants) ✓
Ethernet ports on the 7705 SAR-W ✓
Ethernet ports on the 7705 SAR-Wx (all variants) ✓
DSL ports on the 7705 SAR-Wx ✓
Ethernet ports on the 7705 SAR-X
✓
1
16-port T1/E1 ASAP Adapter card ✓
32-port T1/E1 ASAP Adapter card ✓
2-port OC3/STM1 Channelized Adapter card ✓
4-port OC3/STM1 / 1-port OC12/STM4 Adapter card ✓
4-port OC3/STM1 Clear Channel Adapter card ✓
4-port DS3/E3 Adapter card ✓
T1/E1 ASAP ports on the 7705 SAR-A (variants with T1/E1 ASAP ports ✓
T1/E1 ASAP ports on the 7705 SAR-M (variants with T1/E1 ASAP
ports)
✓
TDM ports on the 7705 SAR-X ✓
