Notifier NFS-3030/E Programming Manual

AWACS™ Applications Detector Status Display
112 NFS-3030 Programming Manual P/N 51345:C 11/4/03
Print a Detector Maintenance Report
A Detector Maintenance Report lists detector maintenance status for each installed addressable
detector [except FDX (an analog heat detector)].
To print this report, press the Printer Function soft key at the Main Menu, then press the Detector
Maintenance Report soft key sends a Detector Maintenance Report (Appendix Figure D-7) to the
printer connected to the control panel.
Appendix Figure D-7 Sample Detector Maintenance Report
How to Interpret a Detector Status Display or Maintenance Report
The Detector Read Status Screen and Detector Maintenance Report provides the same information
(such as Device Status, Peak Value) about a detector. This section contains descriptions of each
item that appears in a Detector Read Status Screen or a Detector Maintenance Report.
Display Information
Lines 1- 4 - This could display any current event message, or, as in this example, the System
Normal message
Line 5 - Screen title and the address of the point being read
The area between the separator lines, lines 6-14, shows all information concerning the selected
point, which is L03D052 in the above example.
Line 6 - Line 6 displays two statistics that display for inputs (detectors and modules) and zones; in
the above example they are:
AUTOMATIC INACTIVE
******DETECTOR MAINTENANCE******************************************************
NORMAL SMOKE(LASER) Detector L01D001 000330us 000340us Comp:000% Pk: 002%
Alarm: 000% PreAlarm: 000% A6P6 V000 L01D001
NORMAL SMOKE ACCLIM Detector L01D002 000030us 000000us Comp:000% Pk: 000%
Alarm: 000% PreAlarm: 000% A8P8 V000 L01D002
Field Identification
State
Label
Extended
Label
Current reading of raw analog
value in microseconds
Long term average of
raw analog value in
microseconds
Compensation
percentage
Detector peak
Address
Percent of
alarm
threshold
Percent of
prealarm
threshold
Verification count
Programmed alarm sensitivity setting in
effect when the report was generated.
Programmed prealarm sensitivity setting in
effect when the report was generated
Alarm: 000% PreAlarm: 000% A6P6 V000 L01D001
NORMAL SMOKE(LASER) Detector L01D001 000330us 000340us Comp:000% Pk: 002%
