Program Point Program
34 NFS-3030 Programming Manual P/N 51345:C 11/4/03
3.4 Point Program
The Point Program allows the programmer to enter/change point information for detectors,
modules, panel circuits, and general, releasing, logic and trouble zones.
Press the Point Programming Menu soft key of the Program/Alter Status Menu to display the
screen below.
Figure 3.22 Point Program Menu
Soft Keys
POINT SELECT: Press until the desired point type appears. The types - detector, module, panel
circuit module, general zone, logic zone, trouble zone, or ACS Board - appear in the parenthesis
after the point formats. Enter the desired point address in the format field.
ACCEPT: Press to progress to the appropriate screen, based on the type of point selected.
NEXT/PREVIOUS SELECTION: Press to scroll backward or forward to the next or previously
installed point.
POINT PROGRAM MENU
POINT SELECT:
LyyDzzz (DETECTOR)
NEXT SELECTION ACCEPT
PREVIOUS SELECTION BACK
