Panel Program Menu (2) Program
NFS-3030 Programming Manual P/N 51345:C 11/4/03 31
Soft Keys
POINT SELECT: Pressing this soft key will invoke the cursor at the underlined field. Enter the
loop number desired (01 through 10) in the yy of the Lyy format.
NEXT/PREVIOUS SELECTION: Press either key to go forward or back through the loop
selections.
ACCEPT: Press to proceed to the Loop Point Programming screen.
Loop Point Programming
Figure 3.18 Loop Point Programming Screen
Soft Keys
INSTALLED: Press this soft key to choose YES or NO, depending on whether an SLC is installed
at this address.
FlashScan and CLIP Mode
FlashScan devices can be programmed to run in either CLIP or FlashScan mode. The types can not
be mixed on a loop: for example, if Loop 1 is programmed with a FlashScan module poll, CLIP
modules may not be used on that loop.
A detector’s LEDs will light a steady green for several seconds while it is subjected to a detector
test during FlashScan polling. Each detector is tested this way on a regular basis. During the short
time the LEDs are on steady, the detector is not providing fire protection.
DETECTOR POLL: Press to select FLASHSCAN or CLIP loop polling.
MODULE POLL: Press to select FLASHSCAN or CLIP loop polling.
RAPID POLL: For CLIP mode only - enable or disable Rapid Poll for CLIP. This feature will poll
the first 20 modules more often to speed response on manual pull stations.
WIRING STYLE: Press to select the NFPA wiring style (4 or 6) of the loop. If Style 6 is entered
when the wiring is Style 4, a trouble message will be generated at the panel.
BLINK MODE: Press to enable (YES) or disable (NO) detector LED blinking for this loop.
3.3.5 Custom Action Message
A Custom Action Message appears when the MORE INFORMATION soft key is pressed when an
event is displayed on the Event Counts screen. This panel supports up to 100 Custom Action
LOOP POINT PROGRAMMING
INSTALLED: YES BLINK MODE: YES
DETECTOR POLL: CLIP
MODULE POLL: CLIP
RAPID POLL: ENABLED ACCEPT
WIRING STYLE: 6 BACK
