Point Program Program
NFS-3030 Programming Manual P/N 51345:C 11/4/03 41
Figure 3.30 Module Point Programming Screen 2 (Monitor)
Soft Keys
CUSTOM ACTION MESSAGE: Displays the custom action message number (a value of one
through 100). The default value is 0 (no message). Press this soft key to progress to the Custom
Action Message screen (shown in Figure 3.26) to view the message or to choose a different
message for viewing when this point activates. (To create a new custom action message, refer to
"Custom Action Message" on page 31.)
ZONE MAP: Displays the zones mapped to this point. During initial programming, zone map
position one for each monitor module is set to Z0YY, where YY represents the loop number where
the module resides. In Figure 3.30 above, zone position one has a value of Z003 (YY = 03). The
module in the example resides on loop 3.
To add or delete zones, press this soft key to proceed to the Module Zone Map screen. Refer to
"Zone Map" on page 36 for an illustration and explanation of the Detector Zone Map screen. The
Module Zone Map screen is the same except that Module replaces Detector in the title and the
module address appears instead of the detector address. Up to ten general, releasing or special
zones may be mapped to a monitor module: none of the zone map positions are fixed.
ALARM VERIFICATION: Press this key to determine participation in Alarm Verification.
Choosing Yes will set the device participation to the value entered at the Panel Timers screen
(Figure 3.7). The only module type that can participate in alarm verification is the FZM-1.
LOCAL MODE: Press to toggle between Local Mode (ON) or no Local Mode (OFF). When there is
a communication loss between the panel and an SLC, the devices on the SLC that have been
selected for Local Mode participation (ON) will continue to function in a limited manner.
Participating input points on the loop will activate output points of the same Type ID designation
on the loop (that is, fire alarm input points will activate fire alarm output points, etc.). Monitor
modules with these categories of Type ID codes can participate in Local Mode: fire alarm,
supervisory, security, trouble. Refer to "Type Codes for Input Devices" on page 124 to determine
which Type ID codes fall into these categories. Default: OFF
Note: The panel setting LCM LOCAL MODE must be set to Yes for local mode to work at the device
level.
ACCEPT: Press to save entries made on this screen and to return to the previous screen.
Module Point Programming (Control Module)
Pressing the MORE soft key at the Module Point Programming screen will display this screen if the
module type was control.
MODULE POINT PROGRAMMING
L03M123
CUSTOM ACTION MESSAGE:020
ZONE MAP:
Z003 , Z104 , Z105 , Z106 , Z107
Z110 , Z114 , Z115 , Z116 , Z117
ALARM VERIFICATION: OFF
LOCAL MODE: OFF ACCEPT
BACK
