Program Point Program
40 NFS-3030 Programming Manual P/N 51345:C 11/4/03
3.4.2 Module Point
Module point programming screens will display if a module point address is entered at the Point
Programming Menu (see Figure 3.22 on page 34 ).
Module Point Programming (1)
Figure 3.29 Module Point Programming (1) Screen
Soft Keys
MODULE TYPE: Press the soft key to toggle between CONTROL and MONITOR.
TYPE CODE LABEL: Press this soft key to scroll through the point type choices: stop at the
appropriate selection.
FLASHSCAN CODE LABEL: Press this soft key to scroll through the point type choices: stop at
the appropriate selection (see Appendix Table G-4 on page 127 for codes and descriptions).
Choose NONE if the point type is not FlashScan.
Note: If the point is not installed, MODULE TYPE: , TYPE CODE LABEL:, and FLASHSCAN
CODE LABEL: must be entered before any entries can be saved using the ACCEPT key.
POINT LABEL: Press this soft key to place the cursor at this field. Type in a 20-character
maximum point label that will appear in message formats. If no entry is made, the field will default
to the point address.
EXTENDED LABEL: Press to place the cursor at this field. Type in a 12-character maximum
extended label to further define the location or nature of the point.
MORE: Press to proceed to the next screen for more point programming.
ACCEPT: Press to save entries made on this screen.
Module Point Programming (Monitor Module)
Pressing the MORE soft key at the Module Point Programming screen will display this screen if the
module type was monitor.
MODULE POINT PROGRAMMING
L03M123
MODULE TYPE: MONITOR
TYPE CODE LABEL:HEAT DETECT
FLASHSCAN CODE LABEL: MONITOR MORE
POINT LABEL:
MONITOR L03M123 ACCEPT
EXTENDED LABEL:
BACK
