Page #126 background image
Type Codes Type Codes for Output Devices
126 NFS-3030 Programming Manual P/N 51345:C 11/4/03
G.4 Type Codes for Output Devices
This section provides a list of Type Codes for SLC control module points and panel circuit output
module points. Select from these codes to define the type of point
Note: Do not assign Releasing Type Codes to panel circuit module points.
Appendix Table G-3 SLC Control Module and Panel Circuit Output Module Type Codes
Type Code
Silenceable
(Y=yes
N=no)*
Switch
Inhibit
(Y=yes,
N=No)*
Walk
Test
(Y=yes,
N=No)*
SLC or Panel Circuit
Output Point
Device Function
CONTROL Y N Y NAC Supervised NAC
RELAY Y N Y Relay Relay output
BELL CIRCUIT Y N Y NAC Supervised NAC
STROBE CKT Y N Y NAC Supervised NAC
HORN CIRCUIT Y N Y NAC Supervised NAC
AUDIBLE CKT Y N Y NAC Supervised NAC
SPEAKER Y N Y NAC Supervised NAC for speaker circuits
blank Y N Y NAC Supervised NAC for undefined device
NONRESET CTL N N N Relay or NAC Supervised output, unaffected by “System Reset” command
TELEPHONE N N N Relay Supervised Telephone circuit
CONTROL NAC Y N Y NAC Supervised NAC
ISOLATED NAC Y N Y NAC Supervised NAC for notification appliance, used with audio
isolators. Activates even if there is a short on its NAC circuit.
For ULC installations only.
ISOLATED SPK Y N Y NAC Supervised NAC for speaker circuits, used with audio isolators.
Activates even if there is a short on its audio circuit. For ULC
installations only.
GEN ALARM N Y Y NAC Control Module, XPC-8, or an XP5-C (in NAC mode) configured as
a Municpal Box Transmitter for NFPA 72 Auxiliary Fire Alarm
Systems applications (MBT-1 required). This Type ID can also be
used for general alarm activation.
GEN SUPERVIS N Y Y NAC Control Module, XPC-8, or an XP5-C (in NAC mode) activated
under any Supervisory condition (includes sprinkler type).
GEN TROUBLE N Y Y NAC Control Module, XPC-8, or an XP5-C (in NAC mode) activated
under any System Trouble condition.This device will not turn ON
when it is in trouble (short or open).
GENERAL PEND N Y Y NAC Control Module XPC-8 circuit, or an XP5-C (in NAC mode) that
will activate upon receipt of an alarm and/or trouble condition,
and remain in the ON state until all events have been
ACKNOWLEDGED. This device will not turn ON when it is in
trouble (short or open)
TROUBLE PEND N Y Y NAC Control Module or an XP5-C (in NAC mode) that will activate upon
receipt of a trouble condition, and remain in the ON state until all
troubles have been ACKNOWLEDGED. This device will not turn
ON when it is in trouble (short or open).
ALARMS PEND N Y Y NAC Control module/panel circuit or NAC for output that will
activate upon receipt of an alarm condition, and remain in the
alarm state until all alarms have been acknowledged.
INST RELEASE N Y N NAC (SLC only) Supervised for open circuits and ground faults. Short = normal
REL. FORM C N Y N Form-C relay (SLC only) Directs relay outputs to perform a releasing function.
RELEASE CKT N Y N NAC (SLC only) Directs outputs to perform a releasing function.
REL CKT ULC N Y N NAC (SLC only) Directs outputs to perform a release function as required by
ULC.
REL END BELL N Y N NAC Activates NAC audio or visual device when releasing circuits
shut off.
REL AUDIBLE Y Y N NAC Activates audio or visual devices steady when releasing starts.
FORM C RESET N Y N Form-C Relay (SLC only)
Control module used to interrupt 24V power to four-wire
conventional detectors for 30 seconds upon reset. Used in
conjunction with a monitor module with a conventional detector
Type ID
* Values represent program defaults.
