Point Program Program
NFS-3030 Programming Manual P/N 51345:C 11/4/03 47
Default:ULI
CROSS ZONE: Press to scroll through the selection list of YES, NO, ZONE, HEAT. Default: NO.
SOAK TIME: Press to type a value from 0 to 9999 (seconds). Default: 0000
3.4.6 Logic Zone
Logic Zone Programming
This screen displays when a logic zone is entered at the Point Programming Menu (see Figure 3.22
on page 34 ).
The logic equation for that zone will display in line 6. Line 4 indicates the current state of the logic
zone (ON or OFF). If there is no equation at the logic zone number entered, nothing will display in
lines 4 and 6, and the user must press the EDIT EQUATION soft key to proceed to the next screen
and enter an equation.
Refer to Appendix E: CBE: Zones and Equations for information on how to create a logic equation,
and how logic equations operate.
Figure 3.38 Logic Zone Programming Menu Screen
Soft Keys
EDIT EQUATION: Press to proceed to the edit screen to add or edit a logic equation.
NEXT/PREVIOUS EQUATION: Press to view the next or previous logic equation.
Edit Logic Equation
This screen displays when the EDIT EQUATION soft key is pressed on the Logic Zone.
LOGIC ZONE PROGRAMMING MENU
LOGIC ZONE ZLxxxx
AUTOMATIC OFF
AND(Z20,OR(L2D159,L2D14))
EDIT EQUATION
NEXT EQUATION ACCEPT
PREVIOUS EQUATION BACK
