Type Codes for Input Devices Type Codes
NFS-3030 Programming Manual P/N 51345:C 11/4/03 125
Type Codes for Monitor Modules
Note: A list of monitor module Type Codes, which you can use to change the function of a monitor
module point.
Note: Do not assign Releasing Type Codes to Panel Circuit module points.
Appendix Table G-2 Type Codes for Monitor Modules
Type Code
Point
Characteristics
Device Function
Point Type
Latching
(Y=yes
N=no)
Activates
CBE
MONITOR fire alarm Y Y Alarm-monitoring device
PULL STATION fire alarm Y Y Manual fire-alarm-activating device
SMOKE CONVEN fire alarm Y Y Indicates activation of a conventional smoke detector. An FZM-1 must be used for
alarm verification of a two-wire conventional detector.
SMOKE DETECT fire alarm Y Y Indicates activation of a conventional smoke detector. An FZM-1 must be used for
alarm verification of a two-wire conventional detector
WATERFLOW fire alarm Y Y Monitor for waterflow alarm switch
WATERFLOW S supervisory Y Y Indicates supervisory condition for activated waterflow switch
ACCESS MONTR non-alarm security N Y Used for monitoring building access
AREA MONITOR security Y Y Monitors building access
AUDIO SYSTEM trouble N N Used for monitoring audio equipment (use trouble zones for activations)
EQUIP MONITR non-alarm security N Y Used for monitoring equipment
SECURITY L security Y Y Indicates activation of security alarm
LATCH SUPERV supervisory Y Y Indicates latching supervisory condition
TRACK SUPERV supervisory N Y Monitors for waterflow tamper switches for alarm points
SPRINKLR SYS supervisory Y Y Monitors a waterflow device
SYS MONITOR security Y Y Monitors equipment security
TAMPER supervisory Y Y Indicates activation of tamper switch
ACK SWITCH non-alarm N N Emulates panel Acknowledge switch
ALLCALL PAGE non-alarm N Y Emulates AMG-1 All-call switch and telephone page
DRILL SWITCH non-alarm N N Emulates panel Drill switch, activates silenceable fire outputs
EVACUATE SWITCH non-alarm N N Emulates panel Drill Switch, activates silenceable fire outputs
FIRE CONTROL non-alarm N Y Monitors non-fire activations
NON FIRE non-alarm N Y Monitors non-fire activations
PAS INHIBIT non-alarm N N Inhibits Positive Alarm Sequence
POWER MONITR trouble N N Monitors main and auxiliary power supplies (use trouble zones for activations)
RESET SWITCH non-alarm N N Emulates keypad Reset switch
SIL SWITCH non alarm N N Emulates keypad Signal Silence switch
TELE PAGE non-alarm N Y Emulates Page Button on FFT-7. Allows remote paging to a fire area
TROUBLE MON trouble N N Monitors trouble inputs (use trouble zones for activations)
Blank fire alarm Y Y Monitors for a device with no description
HEAT DETECT fire alarm Y Y Monitors for conventional heat detector
RF MON MODUL fire alarm Y Y Wireless alarm-monitoring device
RF PULL STA fire alarm Y Y Wireless manual fire-alarm-activating device
RF SUPERVSRY supervisory N Y Wireless supervisory-monitoring device
ABORT SWITCH non-alarm N Y Provides an abort function through a monitor module (connected to a UL-listed
abort station) for a releasing zone.
MAN RELEASE fire alarm Y Y Provides a manual release through a monitor module (connected to a UL-listed pull
station) for a releasing zone
MAN REL DELAY fire alarm Y Y Provides a manual release with a 10-second delay through a monitor module
(connected to a UL-listed pull station) for a releasing zone
SECOND SHOT fire alarm Y Y Provides a second manual release through a monitor module (connected to a UL-
listed pull station) for a releasing zone
