Appendix H: System Troubles
Appendix Table H-1 is a list of System Troubles that could occur during the course of FACP
operation. The System Trouble Name column is the text that displays in the system trouble
message. The System Trouble Index is the number associated with the trouble in FACP memory. It
is the number that can be used as an argument in a Trouble Equation.
Appendix Table H-1 System Trouble Names and Codes
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
0 GROUND FAULT 61 ANNUN 24 TROUBLE 197 STYLE 6 POS LOOP 8 400 REMOTE DISPLAY 9 TROUBLE
1-2 RESERVED 62 ANNUN 24 NO ANSWER 198 STYLE 6 POS LOOP 9 401 REMOTE DISPLAY 9 NO ANSWER
3 STYLE 6 POS LOOP 1 63 ANNUN 25 TROUBLE 199 STYLE 6 POS LOOP 10 402 REMOTE DISPLAY 10 TROUBLE
4 STYLE 6 POS LOOP 2 64 ANNUN 25 NO ANSWER 200-205 RESERVED 403 REMOTE DISPLAY 10 NO ANSWER
5 CORRUPT LOGIC EQUAT 65 ANNUN 26 TROUBLE 206 PRINTER PAPER OUT 404 REMOTE DISPLAY 11 TROUBLE
6 RESERVED 66 ANNUN 26 NO ANSWER 207 PRINTER OFF LINE 405 REMOTE DISPLAY 11 NO ANSWER
7 EPROM ERROR 67 ANNUN 27 TROUBLE 208-209 RESERVED 406 REMOTE DISPLAY 12 TROUBLE
8 INTERNAL RAM ERROR 68 ANNUN 27 NO ANSWER 210 MANUAL MODE ENTERED 407 REMOTE DISPLAY 12 NO ANSWER
9 EXTERNAL RAM ERROR 69 ANNUN 28 TROUBLE 211 NCM COMM LOSS 408 REMOTE DISPLAY 13 TROUBLE
10 PROGRAM CORRUPTED 70 ANNUN 28 NO ANSWER 212 STYLE 4 SHORT A LOOP 1 409 REMOTE DISPLAY 13 NO ANSWER
11 NO DEV INST ON L1 71 ANNUN 29 TROUBLE 213 STYLE 4 SHORT B LOOP 1 410 REMOTE DISPLAY 14 TROUBLE
12 PANEL DOOR OPEN 72 ANNUN 29 NO ANSWER 214 STYLE 4 SHORT A LOOP 2 411 REMOTE DISPLAY 14 NO ANSWER
13 AUXILIARY TROUBLE 73 ANNUN 30 TROUBLE 215 STYLE 4 SHORT B LOOP 2 412 REMOTE DISPLAY 15 TROUBLE
14 RESERVED 74 ANNUN 30 NO ANSWER 216 STYLE 4 SHORT A LOOP 3 413 REMOTE DISPLAY 15 NO ANSWER
15 ANNUN 1 TROUBLE 75 ANNUN 31 TROUBLE 217 STYLE 4 SHORT B LOOP 3 414 REMOTE DISPLAY 16 TROUBLE
16 ANNUN 1 NO ANSWER 76 ANNUN 31 NO ANSWER 218 STYLE 4 SHORT A LOOP 4 415 REMOTE DISPLAY 16 NO ANSWER
17 ANNUN 2 TROUBLE 77 ANNUN 32 TROUBLE 219 STYLE 4 SHORT B LOOP 4 416 REMOTE DISPLAY 17 TROUBLE
18 ANNUN 2 NO ANSWER 78 ANNUN 32 NO ANSWER 220 STYLE 4 SHORT A LOOP 5 417 REMOTE DISPLAY 17 NO ANSWER
19 ANNUN 3 TROUBLE 79 NETWORK FAIL PORT A 221 STYLE 4 SHORT B LOOP 5 418 REMOTE DISPLAY 18 TROUBLE
20 ANNUN 3 NO ANSWER 80 NETWORK FAIL PORT B 222 STYLE 4 SHORT A LOOP 6 419 REMOTE DISPLAY 18 NO ANSWER
21 ANNUN 4 TROUBLE 81 RESERVED 223 STYLE 4 SHORT B LOOP 6 420 REMOTE DISPLAY 19 TROUBLE
22 ANNUN 4 NO ANSWER 82 ADV WALK TEST 224 STYLE 4 SHORT A LOOP 7 421 REMOTE DISPLAY 19 NO ANSWER
23 ANNUN 5 TROUBLE 83 RESERVED 225 STYLE 4 SHORT B LOOP 7 422 REMOTE DISPLAY 20 TROUBLE
24 ANNUN 5 NO ANSWER 84 GROUND FAULT LOOP 2 226 STYLE 4 SHORT A LOOP 8 423 REMOTE DISPLAY 20 NO ANSWER
25 ANNUN 6 TROUBLE 85 STYLE 6 NEG LOOP 1 227 STYLE 4 SHORT B LOOP 8 424 REMOTE DISPLAY 21 TROUBLE
26 ANNUN 6 NO ANSWER 86 STYLE 6 NEG LOOP 2 228 STYLE 4 SHORT A LOOP 9 425 REMOTE DISPLAY 21 NO ANSWER
27 ANNUN 7 TROUBLE 87 GROUND FAULT LOOP 1 229 STYLE 4 SHORT B LOOP 9 426 REMOTE DISPLAY 22 TROUBLE
28 ANNUN 7 NO ANSWER 88 - 89 RESERVED 230 STYLE 4 SHORT A LOOP 10 427 REMOTE DISPLAY 22 NO ANSWER
29 ANNUN 8 TROUBLE 90 PROG MODE ACTIVATED 231 STYLE 4 SHORT B LOOP 10 428 REMOTE DISPLAY 23 TROUBLE
30 ANNUN 8 NO ANSWER 91 LOADING..NO SERVICE 232 RESERVED 429 REMOTE DISPLAY 23 NO ANSWER
31 ANNUN 9 TROUBLE 92 BASIC WALK TEST 233 STYLE 6 SHORT LOOP 1 430 REMOTE DISPLAY 24 TROUBLE
32 ANNUN 9 NO ANSWER 93 NFPA 24HR REMINDER 234 STYLE 6 SHORT LOOP 2 431 REMOTE DISPLAY 24 NO ANSWER
33 ANNUN 10 TROUBLE 94 NVRAM BATT TROUBLE 235 STYLE 6 SHORT LOOP 3 432 REMOTE DISPLAY 25 TROUBLE
34 ANNUN 10 NO ANSWER 95-104 RESERVED 236 STYLE 6 SHORT LOOP 4 433 REMOTE DISPLAY 25 NO ANSWER
35 ANNUN 11 TROUBLE 105 STYLE 6 ON LOOP 3 237 STYLE 6 SHORT LOOP 5 434 REMOTE DISPLAY 26 TROUBLE
36 ANNUN 11 NO ANSWER 106-107 RESERVED 238 STYLE 6 SHORT LOOP 6 435 REMOTE DISPLAY 26 NO ANSWER
37 ANNUN 12 TROUBLE 108 MAN EVAC INITIATED 239 STYLE 6 SHORT LOOP 7 436 REMOTE DISPLAY 27 TROUBLE
38 ANNUN 12 NO ANSWER 109 MAN EVAC RECEIVED 240 STYLE 6 SHORT LOOP 8 437 REMOTE DISPLAY 27 NO ANSWER
39 ANNUN 13 TROUBLE 110-175 RESERVED 241 STYLE 6 SHORT LOOP 9 438 REMOTE DISPLAY 28 TROUBLE
40 ANNUN 13 NO ANSWER 176 GROUND FAULT LOOP 3 242 STYLE 6 SHORT LOOP 10 439 REMOTE DISPLAY 28 NO ANSWER
41 ANNUN 14 TROUBLE 177 GROUND FAULT LOOP 4 243-249 RESERVED 440 REMOTE DISPLAY 29 TROUBLE
42 ANNUN 14 NO ANSWER 178 GROUND FAULT LOOP 5 250 SELF TEST FAILED 441 REMOTE DISPLAY 29 NO ANSWER
43 ANNUN 15 TROUBLE 179 GROUND FAULT LOOP 6 251 NETWORK INCOMPATIBILITY 442 REMOTE DISPLAY 30 TROUBLE
44 ANNUN 15 NO ANSWER 180 GROUND FAULT LOOP 7 252-383 RESERVED 443 REMOTE DISPLAY 30 NO ANSWER
45 ANNUN 16 TROUBLE 181 GROUND FAULT LOOP 8 384 REMOTE DISPLAY 1 TROUBLE 444 REMOTE DISPLAY 31 TROUBLE
46 ANNUN 16 NO ANSWER 182 GROUND FAULT LOOP 9 385 REMOTE DISPLAY 1 NO ANSWER 445 REMOTE DISPLAY 31 NO ANSWER
47 ANNUN 17 TROUBLE 183 GROUND FAULT LOOP 10 386 REMOTE DISPLAY 2 TROUBLE 446 REMOTE DISPLAY 32 TROUBLE
48 ANNUN 17 NO ANSWER 184 STYLE 6 NEG LOOP 3 387 REMOTE DISPLAY 2 NO ANSWER 447 REMOTE DISPLAY 32 NO ANSWER
49 ANNUN 18 TROUBLE 185 STYLE 6 NEG LOOP 4 388 REMOTE DISPLAY 3 TROUBLE 448 SYSTEM INITIALIZATION
50 ANNUN 18 NO ANSWER 186 STYLE 6 NEG LOOP 5 389 REMOTE DISPLAY 3 NO ANSWER 449-502 RESERVED
51 ANNUN 19 TROUBLE 187 STYLE 6 NEG LOOP 6 390 REMOTE DISPLAY 4 TROUBLE 503 SOFTWARE MISMATCH
52 ANNUN 19 NO ANSWER 188 STYLE 6 NEG LOOP 7 391 REMOTE DISPLAY 4 NO ANSWER 504 NO POWER SUPPLY INST
53 ANNUN 20 TROUBLE 189 STYLE 6 NEG LOOP 8 392 REMOTE DISPLAY 5 TROUBLE 505 LOOP 1-2 COMM FAILURE
54 ANNUN 20 NO ANSWER 190 STYLE 6 NEG LOOP 9 393 REMOTE DISPLAY 5 NO ANSWER 506 LOOP 3-4 COMM FAILURE
55 ANNUN 21 TROUBLE 191 STYLE 6 NEG LOOP 10 394 REMOTE DISPLAY 6 TROUBLE 507 LOOP 5-6 COMM FAILURE
56 ANNUN 21 NO ANSWER 192 STYLE 6 POS LOOP 3 395 REMOTE DISPLAY 6 NO ANSWER 508 LOOP 7-8 COMM FAILURE
57 ANNUN 22 TROUBLE 193 STYLE 6 POS LOOP 4 396 REMOTE DISPLAY 7 TROUBLE 509 LOOP 9-10 COMM FAILURE
58 ANNUN 22 NO ANSWER 194 STYLE 6 POS LOOP 5 397 REMOTE DISPLAY 7 NO ANSWER 510 TEST PROGRAM UPDATE
59 ANNUN 23 TROUBLE 195 STYLE 6 POS LOOP 6 398 REMOTE DISPLAY 8 TROUBLE
60 ANNUN 23 NO ANSWER 196 STYLE 6 POS LOOP 7 399 REMOTE DISPLAY 8 NO ANSWER
