3.2 Panel Program
Panel programming provides the means to change settings for the panel system as a whole, as well
to address and program annunciator points.
3.2.1 Panel Program Menu (1)
Press the Panel Program Menu for the following choices.
Figure 3.2 Panel Program Menu 1 Screen
3.2.2 Network Parameters
Press the Network Parameters soft key on Panel Program Menu 1 to bring up the following screen.
If the panel will operate as a standalone unit and not part of a network, the node label is the only
field that needs to be entered: it is the label that appears as part of the System Normal message.
Figure 3.3 Network Programming Screen
Soft Keys
NODE NUMBER: Enter the network node number of this panel. For standalone NFS-3030/E, the
network node number will be 000. A valid network node number range is 1-240. Once the soft key
has been pressed, the number may be typed in from the keypad, or the Next/Previous Selection
special function key on the keypad may be used to toggle through online node numbers. The
network node number may be viewed by pressing the Lamp Test special function key longer than
five seconds. (Refer to "Version Information" on page 71 ). Default: 000
PANEL PROGRAM MENU
NETWORK PARAMETERS LCD DISPLAY
ACS PROGRAMMING
PANEL SETTINGS SUPERVISION
PANEL TIMERS MORE
BACK
NETWORK PROGRAMMING
NODE NUMBER: 000
NODE LABEL:
LAKEVIEW GENERAL HOSPITAL
STYLE: STYLE 7
CH A. THRESHOLD: HIGH ACCEPT
CH B. THRESHOLD: LOW BACK
