Control On/Off Point Select Alter Status
NFS-3030 Programming Manual P/N 51345:C 11/4/03 69
4.8 Control On/Off Point Select
This screen may be used to force a control module (SLC or panel circuit) off if it is on, or on if it is
off.
Figure 4.13 Control On/Off Point Select Screen
Soft Keys
POINT: Press this soft key to enter the point address to be forced on or off.
Note: A module with a releasing Type ID cannot be forced.
NEXT/PREVIOUS SELECTION: Press to progress to the next or previous point on the loop.
ACCEPT: Press to continue to the Control On or Control Off screen.
4.8.1 Control Off
One of the following two screens will display when a point is selected and accepted in the previous
screen.
If the selected point is active, the Control Off screen will appear.
Figure 4.14 Control Off Screen
Soft Keys
FORCE OFF: Press this soft key to change the state of the control module from
AUTOMATIC
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI JAN 25, 2002
POINT SELECT
POINT: LyyMzzz (MODULE)
NEXT SELECTION ACCEPT
PREVIOUS SELECTION BACK
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI JAN 25, 2002
CONTROL ON/OFF: L03M052
AUTOMATIC ACTIVE
ELEVATOR RECALL EAST WING
FIFTH FLOOR Z000 CONTROL
FORCE OFF BACK
