Notifier NFS-3030/E Programming Manual

Abort Switches Releasing Applications
NFS-3030 Programming Manual P/N 51345:C 11/4/03 81
The abort switch selection (ULI, IRI, NYC, or AHJ) determines the function of the abort switch.
Appendix Figure B-3 Example of a Basic Configuration for an Abort Switch
Type Code
RELEASE CKT
Type Code
REL CKT ULC
Type Code
REL AUDIBLE
Type Code
REL END BELL
Example: If you program these three output modules
as shown, these outputs activate at release.
Example: If you program a
fourth module as shown,
this output activates when
the release is finished.
ZR05
Monitor
Module with
ABORT SWITCH
Type Code
Detector
Detector
Abort station with Abort Switch
and Manual Release lever
Output
Module
SYSTEM
NORMAL
SYSTEM
ACTIVATED
Output
Module
Output
Module
Output
Module
