6 Remove the coffee nozzle; clip and top pis-
ton of the group.
7 Loosen the 4 screws on the front panel with
a philips screw driver.
8 slide down the front panel.
9 Remove the front panel from the front.
10 Remove the motor plug on top of the
machine.
11 Disconnect the heating element and probe
plug.
Edition 02 to 02/2014
3.3
SERVICE MANUAL
6
Fig. 52
00:27
7
7 7
7
8
9
Fig. 53
00:30
10
Fig. 54
00:39
11
Fig. 55
00:41
