8 Slide out the piston out from the top.
9 Using a flathead screwdriver, take out the
screw securing the shower to the piston
clean the shower with a damp cloth or
leave to soak in hot water and pulicaff.
If the shower is too dirty,
replace it with a new one.
Make sure that the piston surface are clean.
10 With a 21 mm wrench, undo the screw that
holds the seal.
11 Remove a slide out with one finger and
replace it.
Edition 02 to 02/2014
4.5
SERVICE MANUAL
Fig. 91
01:20
Fig. 92
Fig. 93
01:30
Fig. 94
01:35
