11-12 Open the front panel by loosening the 4
screws.
13-14 Remove the Teflon pipe, and with a
Phillips screwdriver, unscrew the two
screws holding the boiler tank.
15 Remove the boiler from behind.
16 The solenoid valve is connected directly to
the coffee boiler to keep the water warmer
and always ready for brewing.
Edition 02 to 02/2014
6.7
SERVICE MANUAL
Fig. 153
03:19
Fig. 155
03:30
Fig. 154
03:27
Fig. 156
03:33
