136 Océ TDS600 Multifunctional Digital System User Manual
[86] System Control Panel window
Note:
You can hide the media by de-selecting it in the View menu option.
Icons
The Océ TDS600 System Control Panel uses a number of icons to display
information about the media available on the printer. The following icons are
used:
The material is available and the roll is ready for printing.
The roll is disabled.
The roll is enabled but empty.
The material is available in portrait orientation and the sheetfeeder
is ready for printing.
The material is available in landscape orientation and the
sheetfeeder is ready for printing.
The sheetfeeder is empty and material should be loaded in portrait
orientation.
