- 79 -
3. Maintenance
7
Hold the lock levers (b) of a new belt unit and place the belt unit into the
machine.
8
Turn the lock levers (b) on the both sides of the belt unit backward.
9
Return all the four image drums to the machine.
While setting the image drum, be careful not to hit it to the LED head.
10
Close the output tray (a) slowly and push the center of the tray for
confirmation.
To Next Page
