Oki C542dn Advanced Manual

- 129 -
5. Operating Management/ Specifications
• Network Setup
• Mail Server Setup
• LDAP Server Setting
• Secure Protocol Server Setting
Network Setup
•Network Setting
• Wireless (Infrastructure) Setting (If wireless LAN module fitted)
Network Menu
Item Factory default setting Description
Enabling Default Gateway Wired Sets which default gateway to be enabled between
wired LAN or wireless LAN.
This item is displayed, if wireless LAN module
fitted.
Wired Enable Sets whether to enable wired LAN.
TCP/IP Enable Sets whether to enable TCP/IP.
NetBIOS over TCP Enable Sets whether to enable NetBIOS over TCP/IP.
This item is displayed when TCP/IP protocol is
enabled.
IP Address Set Auto Sets the method of assigning an IP address.
IPv4 Address 192.168.100.100 Sets an IP address.
This item is displayed when TCP/IP protocol is
enabled.
Subnet Mask 255.255.255.0 Sets a subnet mask.
This item is displayed when TCP/IP protocol is
enabled.
Gateway Address 0.0.0.0 Sets a gateway address.
This item is displayed when TCP/IP protocol is
enabled.
DHCPv6 Disable Selects enable / disable of DHCP when IPv6 is
used.
DNS Server (Primary) 0.0.0.0 Sets the IP address for a Primary DNS server.
This item is displayed when TCP/IP protocol is
enabled.
DNS Server (Secondary) 0.0.0.0 Sets the IP address for a Secondary DNS server.
This item is displayed when TCP/IP protocol is
enabled.
WINS Server (Primary) 0.0.0.0 Sets the name or the IP address for the WINS
server.
This item is displayed when TCP/IP protocol is
enabled.
WINS Server (Secondary) 0.0.0.0 Sets the name or the IP address for the WINS
server.
This item is displayed when TCP/IP protocol is
enabled.
Proxy Disable Sets whether to use proxy.
Proxy Server (NULL) Sets the name or IP address of the proxy server.
You can enter up to 15 characters.
Proxy Server Port No. 8080 Sets the port number of the proxy server.
Proxy User ID (NULL) Sets the user ID to connect to the proxy server.
Proxy Password (NULL) Sets the password to connect to the proxy server.
Web Enable Sets whether to enable access from a Web
browser.
This item is displayed when TCP/IP protocol is
enabled.
Telnet Disable Sets whether to enable access from the Telnet.
This item is displayed when TCP/IP protocol is
enabled.
FTP Disable Sets whether to enable access with FTP.
This item is displayed when TCP/IP protocol is
enabled.
IPSec Disable This item is displayed only if IPSec is set to valid.
This item can be changed to disable only.
[Enable] can only be set on the web page.
SNMP Enable Sets whether to enable access from SNMP.
This item is displayed when NetWare or TCP/IP
protocol is enabled.
Network Scale Normal [Normal]: The machine operates effectively even if
connected to a HUB with the spanning tree
function. However, the machine takes longer to
start up if it is connected to a small LAN that
consists of two or three computers.
[Small]: This setting covers a small LAN that
consists of two or three computers to a large LAN,
but the machine may not operate efficiently if it is
connected to a HUB with the spanning tree
function.
Gigabit Network Disable Sets whether to enable access with Gigabit
Ethernet.
HUB Link Setting Auto Sets the hub linking method. Normally, select [Auto
Negotiate].
Item Factory default setting Description
Wireless(Infrastructure) Disable Sets whether to enable Wireless(Infrastructure).
Item Factory default setting Description
