4-101
4-2 Function Mode
4
Functions
10D6h STOP key selection b087 R/W
00: Enabled
01: Disabled
⎯
10D7h Free-run stop selection b088 R/W
00: 0 Hz start
01: Frequency pull-in restart
⎯
10D8h Monitor display selection b089 R/W
01: Output frequency monitor
02: Output current monitor
03: Rotation direction monitor
04: PID feedback value monitor
05: Multi-function input monitor
06: Multi-function output monitor
07: Frequency conversion monitor
⎯
10DAh Stop selection b091 R/W
00: Deceleration→Stop
01: Free-run stop
⎯
10DBh Cooling fan control b092 R/W
00: Always ON
01: ON during RUN
02: Depends on the fin temperature
⎯
10F5h
Overvoltage LAD stop
function
b130 R/W
00: Disabled
01: Enabled
⎯
10F6h
Overvoltage LAD stop
function level setting
b131 R/W
200-V class: 330 to 395,
400-V class: 660 to 790
1. [V]
1176h
Overvoltage protection
function selection during
deceleration
b133 R/W
00: Disabled
01: Enabled
⎯
1177h
Overvoltage protection level
setting during deceleration
b134 R/W
200-V class: 330. to 395.
400-V class: 660. to 790.
1. [V]
10F7h
Overcurrent suppression
function
b140 R/W
00: Disabled
01: Enabled
⎯
10F8h Automatic carrier reduction b150 R/W
00: Disabled
01: Enabled
⎯
10F9h Ready function selection b151 R/W
00: RDY disabled
01: RDY enabled
⎯
Register
No.
Function name
Parameter
No.
R/W
Function
Monitor or data range
Resolution
