Omron 3G3JX

4-102
4-2 Function Mode
4
Functions
1103h
Multi-function input 1
selection
C001 R/W
00: FW/01: RV/02: CF1/03: CF2/04:
CF3/05: CF4/06: JG/07: DB/08: SET/09:
2CH/11: FRS/12: EXT/13: USP/15: SFT/
16: AT/18: RS/19: PTC terminal 5 only/
20: STA/21: STP/22: F/R/23: PID/24:
PIDC/27: UP/28: DWN/29: UDC/31:
OPE/50: ADD/51: F-TM/52: RDY/53:
SP-SET/64: EMR(automatically
allocated to terminal 3 if enabled)/255:
NO
⎯
1532h
2nd multi-function input 1
selection
C201 R/W
1104h
Multi-function input 2
selection
C002 R/W
1533h
2nd multi-function input 2
selection
C202 R/W
1105h
Multi-function input 3
selection
C003 R/W
1534h
2nd multi-function input 3
selection
C203 R/W
1106h
Multi-function input 4
selection
C004 R/W
1535h
2nd multi-function input 4
selection
C204 R/W
1107h
Multi-function input 5
selection
C005 R/W
1536h
2nd multi-function input 5
selection
C205 R/W
110Bh
Multi-function input 1
operation selection
C011 R/W
00: NO
01: NC
⎯
110Ch
Multi-function input 2
operation selection
C012 R/W
110Dh
Multi-function input 3
operation selection
C013 R/W
110Eh
Multi-function input 4
operation selection
C014 R/W
110Fh
Multi-function input 5
operation selection
C015 R/W
1114h
Multi-function output
terminal P1 selection
C021 R/W
00: RUN/01: FA1/02: FA2/03: OL/04:
OD/05: AL/06: Dc/07: FBV/08: NDc/09:
LOG/10: ODc(Do not use.)/43: LOC
⎯
1119h
Relay output (MA, MB)
function selection
C026 R/W
111Bh AM selection C028 R/W
00: F (Output frequency)
01: A (Output current)
⎯
111Dh
Multi-function output
terminal P1 contact selection
C031 R/W
00: NO
01: NC
⎯
1
122h
Relay output (MA, MB)
contact selection
C0
36 R/W
00: NO
01: NC
⎯
1178h
Light load signal output
mode
C038 R/W
00: Enabled during acceleration/
deceleration/constant speed
01: Enabled only during constant speed
⎯
1179h Light load detection level C039 R/W
0 to 20000
Set to10000 at rated current
0.01 [%]
Register
No.
Function name
Parameter
No.
R/W
Function
Monitor or data range
Resolution
