Omron 3G3JX

4-103
4-2 Function Mode
4
Functions
1124h Overload warning level C041 R/W
0 to 20000
Set to10000 at rated current
0.01 [%]
153Ah 2nd overload warning level C241 R/W
1126h
Arrival frequency during
acceleration
C042 R/W 0 to 4000 0.1 [Hz]
1128h
Arrival frequency during
deceleration
C043 R/W 0 to 4000 0.1 [Hz]
1129h
PID deviation excessive
level
C044 R/W 0 to 1000 0.1 [%]
112Eh PID FB upper limit C052 R/W 0 to 1000 0.1 [%]
112Fh PID FB lower limit C053 R/W 0 to 1000 0.1 [%]
1137h Operator/ModBus selection C070 ⎯
Do not change through ModBus
communication. For setting, refer to
"ModBus Setting" (4-78).
⎯
1138h
Communication speed
selection
(Baud rate selection)
C071 ⎯
1139h
Communication station No.
selection
C072 ⎯
113Bh
Communication parity
selection
C074 ⎯
113Ch
Communication stop bit
selection
C075 ⎯
113Dh
Communication error
selection
C076 ⎯
113Eh
Communication error
timeout
C077 ⎯
113Fh Communication wait time C078 ⎯
1141h FV adjustment C081 R/W 0 to 2000 0.1 [%]
1142h FI adjustment C082 R/W 0 to 2000 0.1 [%]
1145h AM offset adjustment C086 R/W 0 to 100 0.1 [V]
⎯ Not used C091 ⎯ Do not change. ⎯
1149h UP/DWN selection C101 R/W 00: OFF/01: ON ⎯
114Ah Reset selection C102 R/W
00: Trip reset at power-on
01: Trip reset when the power is OFF
02: Enabled only during trip (Reset when
the power is ON.)
⎯
1150h
Logic operation function A
input
C141 R/W
00: RUN/01: FA1/02: FA2/03: OL/04:
OD/05: AL/06: Dc/07: FBV/08: NDc/10:
ODc(Do not use.)/43: LOC
⎯
1151h
Logic operation function B
input
C142 R/W
1152h Logic operator selection C143 R/W 00: AND/01: OR/02: XOR ⎯
Register
No.
Function name
Parameter
No.
R/W
Function
Monitor or data range
Resolution
