Omron ACCURAX G5 - Position Control Unit-Servo Relay Unit Cable Specifications

3-122
3-5 Servo Relay Units and Cable Specifications
Accurax G5 AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
3
Specifications
Position Control Unit-Servo Relay Unit Cable Specifications
Position Control Unit Cable (XW2Z-xJ-A3)
This cable connects a Programmable Controller (CQM1H-PLB21) to a Servo Relay Unit
(XW2B-20J6-3B).
Cable types
Connection configuration and external dimensions
Wiring
Model Length (L)
Outer diameter of
sheath
Weight
XW2Z-050J-A3 50 cm
7.5 dia.
Approx. 0.1 kg
XW2Z-100J-A3 1 m Approx. 0.1 kg
L
25
639
32.2
t=15
CQM1 side
CQM1H-PLB21
Servo Relay Unit side
XW2B-20J6-3B
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
15
12
13
14
3
1
4
5
6
Number Number
Servo Relay Unit side
Cable: AWG28 × 4P + AWG28 × 4C
CQM1 side
Hood cover
