3-1 Driver Specifications
Accurax G5 AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
3
Specifications
3-1 Driver Specifications
Select the Servo Drive matching the Servomotor to be used. Refer to "Servo Drive and
Servomotor Combination List"(P.2-11).
The same Accurax G5 AC Servo Drive can be used for either a pulse train input or analog
input. You can change the CONTROL mode according to the controller. (The default setting is
for position control with pulse train commands.)
General Specifications
Note 1. The above items reflect individual evaluation testing. The results may differ under compound conditions.
Note 2. Never perform dielectric strength or other megameter tests on the Servo Drive. Failure to follow this guideline
may result in damaging the internal elements.
Note 3. Depending on the operating conditions, some Servo Drive parts will require maintenance. For details, refer to
"11-5 Periodic Maintenance" (P.11-22).
Item Specifications
Ambient operating
temperature and operating
humidity
0 to +55C, 90% RH max. (with no condensation)
Storage ambient temperature
and humidity
-20 to +65C, 90% RH max. (with no condensation)
Operating and storage
atmosphere
No corrosive gases
Vibration resistance
10 to 60 Hz and at an acceleration of 5.88 m/s
2
or less (Not to be run continuously at
the resonance point)
Impact resistance
Acceleration of 19.6 m/s
2
max. 2 times each in X, Y, and Z directions
Insulation resistance Between power supply terminal/power terminal and FG terminal: 0.5 MΩ min. (at 500
VDC Megger)
Dielectric strength Between power supply/power line terminals and FG terminal: 1,500 VAC for 1 min at
50/60 Hz
Protective structure Built into panel
EC
directive
EMC
directive
EN 55011, EN 61000-6-2, IEC 61800-3
Low voltage
command
EN 61800-5-1
UL standards UL 508C
CSA standards CSA22.2 No. 14
Functional safety EN ISO13849-1:2008 (Performance Level d), IEC61800-5-2:2007 (STO),
EN61508:2001 (SIL2),EN954-1:1996 (CAT3)
