Page #117 background image
96
Communications Functions Section 1-9
Note 1. If an improper setting is used, a non-fatal error will occur, AR 1302 will be
turned ON, and the default setting (0, 00, or 0000) will be used.
2. For information on the host link settings for another OMRON PC, refer to
that PCs Operation Manual.
3. If an out-of-range value is set, the following communications conditions will
result. In that case, reset the value so that it is within the permissible range.
Communications mode: Host Link
Communications format: Standard settings
(1 start bit, 7-bit data; even parity, 2 stop bits,
9,600 bps)
Transmission delay: No
Node number: 00
DM 6651 00 to 07
Baud rate
1
00: 1.2K, 01: 2.4K, 02: 4.8K, 03: 9.6K, 04: 19.2K
00
(Any value
is OK)
08 to 15
Frame format
1
Start Length Stop Parity
00: 1 bit 7 bits 1 bit Even
01: 1 bit 7 bits 1 bit Odd
02: 1 bit 7 bits 1 bit None
03: 1 bit 7 bits 2 bit Even
04: 1 bit 7 bits 2 bit Odd
05: 1 bit 7 bits 2 bit None
06: 1 bit 8 bits 1 bit Even
07: 1 bit 8 bits 1 bit Odd
08: 1 bit 8 bits 1 bit None
09: 1 bit 8 bits 2 bit Even
10: 1 bit 8 bits 2 bit Odd
11: 1 bit 8 bits 2 bit None
00
(Any value
is OK)
DM 6652 00 to 15
Transmission delay (Host Link)
1
0000 to 9999: In ms.
0000
DM 6653 00 to 07
Node number (Host link)
1
00 to 31 (BCD)
00 to 31
08 to 15 Not used. 00
(Any value
is OK)
Word Bit Function Setting
