Omron CPM1 Programming Manual

315
Special Math Instructions Section 5-22
If bit 13 of C is set to 1, the graph will be reflected from left to right, as shown
in the following diagram.
The following example demonstrates the construction of a linear approxima-
tion with 12 line segments. The block of data is continuous, as it must be, from
DM 0000 to DM 0026 (C to C + (2
× 12 + 2)). The input data is taken from IR
010, and the result is output to IR 011.
In this case, the input data word, IR 010, contains #0014, and f(0014) = #0726
is output to R, IR 011.
X
0
X
m
X
Y
X
m
X
0
X
Y
DM 0000 $C00B
DM 0001 $05F0 X
12
DM 0002 $0000 Y
0
DM 0003 $0005 X
1
DM 0004 $0F00 Y
1
DM 0005 $001A X
2
DM 0006 $0402 Y
2
DM 0025 $05F0 X
12
DM 0026 $1F20 Y
12
APR(––)
DM 0000
010
011
00000
1 1 0 0 0 0 0 0 0 0 0 0 1 0 1 1
Bit
15
Bit
00
(Output and
input both BIN)
(m–1 = 11: 12 line
segments)
Address Instruction Operands
00000 LD 00000
00001 APR(––)
DM 0000
010
011
Content Coordinate
X
Y
$1F20
$0F00
$0726
$0402
(0,0)
$0005 $0014 $001A $05F0
(x,y)
