Omron CPM1 Programming Manual

407
CQM1 Cycle Time and I/O Response Time Section 7-1
65 PULS Pulse output from an output bit: 2.5
109.0 Number of pulses specified by word
137.8 Number of pulses specified by *DM
Pulse output from ports 1 and 2:
337.3 Number of pulses specified by word
360.3 Number of pulses specified by *DM
66 SCL 105.8 Word designation 2.5
180.5 *DM designation
67 BCNT 88.4 Counting a word 2.5
49.32 ms Counting 6,656 words via *DM
68 BCMP 140.0 Comparing constant, results to word 2.5
143.0 Comparing word, results to word
194.7 Comparing *DM, results to *DM
69 STIM 36.8 Word-set one-shot interrupt start 2.5
73.8 *DM-set one-shot interrupt start
37.3 Word-set scheduled interrupt start
74.3 *DM-set scheduled interrupt start
66.4 Word-set timer read
113.6 *DM-set timer read
35.3 Word-set timer stop
35.6 *DM-set timer stop
87 DSW 70.3 Word-set 4-digit CS output 2.5
70.3 Word-set 4-digit RD output
89.1 Word-set 4-digit data input
93.1 *DM-set 4-digit CS output
93.1 *DM-set 4-digit RD output
110.3 *DM-set 4-digit data input
74.7 Word-set 8-digit CS output
75.1 Word-set 8-digit RD output
105.5 Word-set 8-digit data input
103.5 *DM-set 8-digit CS output
103.9 *DM-set 8-digit RD output
131.5 *DM-set 8-digit data input
88 7SEG 78.7 4 digits, word designation 2.5
102.6 4 digits, *DM designation
92.1 8 digits, word designation
117.2 8 digits, *DM designation
89 INT 53.0 Set masks via word 2.5
80.8 Set masks via *DM
49.9 Clear interrupts via word
73.2 Clear interrupts via *DM
50.7 Read mask status via word
71.9 Read mask status via *DM
64.8 Change counter SV via word
88.1 Change counter SV via *DM
27.5 Mask all interrupts via word
27.5 Mask all interrupts via *DM
28.5 Clear all interrupts via word
28.5 Clear all interrupts via *DM
Code Mnemonic ON execution
time (µs)
Conditions OFF execution
time (µs)

Omron CPM1 Specifications

General

Model	CPM1
Manufacturer	Omron
Instruction Set	Basic and advanced instructions
Power Supply	100 to 240 VAC or 24 VDC
Communication	RS-232C
I/O Points	10, 20, 30, or 40 points depending on the model
Timers	Yes, multiple timers available
Counters	Yes, multiple counters available
Input Voltage	24V DC
Output Type	Relay or transistor
Number of I/O Points	10, 20, 30, 40
Communication Ports	RS-232C (optional)
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C
Humidity	10% to 90% (non-condensing)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
Program Memory	2048 steps (2K steps)
