406
CQM1 Cycle Time and I/O Response Time Section 7-1
63 CTBL High-speed counter 0 or pulse output from an output bit: 2.5
210.3 Target table with 1 target in words and start
233.8 Target table with 1 target in *DM and start
1.31 ms Target table with 16 targets in words and start
1.33 ms Target table with 16 targets in *DM and start
1.25 ms Range table in words and start
1.27 ms Range table in *DM and start
170.8 Target table with 1 target in words
194.3 Target table with 1 target in *DM
1.27 ms Target table with 16 targets in words
1.30 ms Target table with 16 targets in *DM
1.09 ms Range table in words
1.11 ms Range table in *DM
High-speed counters 1 and 2 or pulse output from ports 1 and 2:
692.8 Target table with 1 target in words and start
721.8 Target table with 1 target in *DM and start
2.79/7.84 ms Target table with 16/48 targets in words and start
2.81/7.86 ms Target table with 16/48 targets in *DM and start
2.26 ms Range table in words and start
2.27 ms Range table in *DM and start
488.8 Target table with 1 target in words
517.8 Target table with 1 target in *DM
2.57/7.67 ms Target table with 16/48 targets in words
2.61/7.72 ms Target table with 16/48 targets in *DM
2.19 ms Range table in words
2.21 ms Range table in *DM
Absolute high-speed counters 1 and 2:
600.8 Target table with 1 target in words and start
624.8 Target table with 1 target in *DM and start
6.46 ms Target table with 48 targets in words and start
6.47 ms Target table with 48 targets in *DM and start
1.47 ms Range table in words and start
1.50 ms Range table in *DM and start
460.8 Target table with 1 target in words
484.8 Target table with 1 target in *DM
6.02 ms Target table with 48 targets in words
6.03 ms Target table with 48 targets in *DM
1.45 ms Range table in words
1.47 ms Range table in *DM
64 SPED Pulse output from an output bit: 2.5
118.4 Frequency specified by constant
123.2 Frequency specified by word
146.8 Frequency specified by *DM
Pulse output from ports 1 and 2:
302.3 Frequency specified by constant
310.3 Frequency specified by word
320.3 Frequency specified by *DM
Code Mnemonic ON execution
time (µs)
Conditions OFF execution
time (µs)
