Omron CPM1 Programming Manual

471
Memory Areas Appendix C
SR 252 00 High-speed Counter Reset Bit 48
01 to 07 Not used.
08 Peripheral Port Reset Bit
Turn ON to reset peripheral port. (Not valid when peripheral device is connected.) Auto-
matically turns OFF when reset is complete.
94
09 Not used.
10 PC Setup Reset Bit
Turn ON to initialize PC Setup (DM 6600 through DM 6655). Automatically turns OFF
again when reset is complete. Only effective if the PC is in PROGRAM mode.
3
11 Forced Status Hold Bit (See note.)
OFF: The forced status of bits that are forced set/reset is cleared when switching
between PROGRAM mode and MONITOR mode.
ON: The status of bits that are forced set/reset are maintained when switching between
PROGRAM mode and MONITOR mode.
The status of this bit can be maintained when PC power turns off by using the PC Setup.
17
12 I/O Hold Bit (See note.)
OFF: IR and LR bits are reset when starting or stopping operation.
ON: IR and LR bit status is maintained when starting or stopping operation.
The status of this bit can be maintained when PC power turns off by using the PC Setup.
17
13 Not used.
14 Error Log Reset Bit
Turn ON to clear error log. Automatically turns OFF again when operation is complete.
441
15 Not used.
SR 253 00 to 07 FAL Error Code
The error code (a 2-digit number) is stored here when an error occurs. The FAL number is
stored here when FAL(06) or FALS(07) is executed. This word is reset (to 00) by execut-
ing a FAL 00 instruction or by clearing the error from a Peripheral Device.
209
08 Not used.
09 Cycle Time Overrun Flag
Turns ON when a cycle time overrun occurs (i.e., when the cycle time exceeds 100 ms).
---
10 to 12 Not used.
13 Always ON Flag ---
14 Always OFF Flag ---
15 First Cycle Flag
Turns ON for 1 cycle at the start of operation.
---
SR 254 00 1-minute clock pulse (30 seconds ON; 30 seconds OFF) ---
01 0.02-second clock pulse (0.01 second ON; 0.01 second OFF) ---
02 Negative (N) Flag ---
03 to 05 Not used.
06 Differential Monitor Complete Flag
Turns ON when differential monitoring is complete.
136
07 STEP(08) Execution Flag
Turns ON for 1 cycle only at the start of process based on STEP(08).
210
08 to 15 Not used.
Word(s) Bit(s) Function Page

Omron CPM1 Specifications

General

Model	CPM1
Manufacturer	Omron
Instruction Set	Basic and advanced instructions
Power Supply	100 to 240 VAC or 24 VDC
Communication	RS-232C
I/O Points	10, 20, 30, or 40 points depending on the model
Timers	Yes, multiple timers available
Counters	Yes, multiple counters available
Input Voltage	24V DC
Output Type	Relay or transistor
Number of I/O Points	10, 20, 30, 40
Communication Ports	RS-232C (optional)
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C
Humidity	10% to 90% (non-condensing)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
Program Memory	2048 steps (2K steps)
