Page #79 background imageLoading...
Page #79 background image
58
CQM1 Interrupt Functions Section 1-5
Controlling High-speed Counter 1 and 2 Interrupts
1,2,3... 1. Use the CTBL(63) instruction to save the comparison table in the CQM1
and begin comparisons.
If C is set to 000, then comparisons will be made by the target matching
method; if 001, then they will be made by the range comparison method.
The comparison table will be saved, and, when the save operation is com-
plete, then comparisons will begin. While comparisons are being executed,
high-speed interrupts will be executed according to the comparison table.
For details on the contents of the comparison tables that are saved, refer
to the explanation of the CTBL(63) instruction in SECTION 5 Instruction
Set.
Note The comparison results are normally stored in AR 1100 through
AR 1107 while the range comparison is being executed.
If C is set to 002, then comparisons will be made by the target matching
method; if 003, then they will be made by the range comparison method.
For either of these settings, the comparison table will be saved, but com-
parisons will not begin, and the INI(61) instruction must be used to begin
comparisons.
2. To stop comparisons, execute the INI(61) instruction as shown below.
Specify port 1 or 2 in P (P=001 or 002).
To start comparisons again, set the second operand to “000” (execute
comparison), and execute the INI(61) instruction.
Once a table has been saved, it will be retained in the CQM1 during oper-
ation (i.e., during program execution) as long as no other table is saved.
Reading the PV
There are two ways to read the PV. The first is to read it from SR 232 and SR
233 (port 1) or SR 234 and SR 235 (port 2), and the second is to use
PRV(62).
Reading SR 232 and SR 233 or SR 234 and SR 235
The PV of high-speed counter 1 is stored in SR 232 and SR 233, and the PV
of high-speed counter 2 is stored in SR 234 and SR 235 as shown below. In
linear mode, the leftmost digit will be F for negative values.
(@)CTBL(63)
P
C
TB
P: Port
001: Port 1
002: Port 2
C: (3 digits BCD)
000: Target table set and comparison begun
001: Range table set and comparison begun
002: Target table set only
003: Range table set only
TB: Beginning word of comparison table
(@)INI(61)
P
001
000
Leftmost 4 digits Rightmost 4 digits Linear Mode Ring Mode
SR 233 SR 232 F8388607 to 08388607
(–8,388,607 to 8,388,607)
00000000 to 00064999Port 1:
SR 235 SR 234Port 2:
