Omron i4L Series - Optional Cables

1-6-5
Optional Cables
This section provides information about optional cables that are available.
XIO Cable
XBELTIO
Adapter Cable
Belt Encoder
Y-adapter Cable
XIO Breakout
Cable
EXPIO to
IO Blox Cable
XBELTIO Adapter Cable
The optional XBELTIO adapter cable connects to the XBELTIO connector on the Primary Interface
Panel. It provides connections for belt encoder, force sensor, RS-232, and IO Blox signals.
1 Overview
1-17
i4L Robots User's Manual (I658)
1-6 Optional Hardware
1
1-6-5 Optional Cables
