124 LD-250 Platform User's Guide 20472-000 Rev B
7.4 Operator Panel
Figure 7-4 Standard Operator Panel (units are mm)
Callout Description Callout Description
A Emergency stop button (E-Stop) E Hole for 15-pin high density D-
Sub connector
B Brake release button (yellow) F 2x 5.3 mm (0.120 inch) through
hole
C On button (green) G 7x 5.4 mm (0.213 inch) through
hole
D Off button (red)
A larger touch-screen is an available option. See: Touchscreen on page 188.
LD-250 Status Screen
The status video screen is a color TFT, 320 x 240 pixels, 3.5 inches diagonal. An optional color
touchscreen supplements or replaces the status screen. See: Touchscreen on page 188.
It is normal for the status screen to go dark (sleep) during operation. Tap lightly on the screen
to resume the display.
Default and Sample Screen Contents
The following image shows the first screen that appears during boot-up:
Figure 7-5 Initial Boot Screen
