3.7 Installing the Docking Station
Callout Description
F Engagement roller. Guides the AMR's charging funnel onto the docking sta-
tion. This is a replaceable wear item.
G Manual charging connector. Use for charging spare batteries outside the AMR.
H Triangle target. The concave triangular back of the charging station provides a
laser reflection as a navigation cue for the AMR, enabling it to align itself accur-
ately for charging.
Docking Station Requirements
The input circuit must provide overcurrent protection consisting of one or more circuit break-
ers, cartridge fuses, or Type S plug fuses of an acceptable type and rating in accordance with
National Electrical Code (NFPA 70) or other local standards.
!
CAUTION: FIRERISK
Use only on circuits provided with 10 amperes branch circuit protection in
accordance with National Electrical Code, NFPA70, or other local electrical
standards.
Operational requirements for the docking station are:
l
100-240 VAC, 50/60 Hz, 8 A (The docking station's power converter automatically
detects the source voltage.)
l
Ambient operating temperature: 5 to 40°C (41 to 104°F)
l
5% to 95% humidity, non-condensing
Required Tools and Fasteners
You require the tools and fasteners described in Table 3-3.
Table 3-3 Required Tools and Fasteners
Size Qty Description
#2 1 Cross-point (Phillips) screwdriver.
As required 1 Appropriate screwdriver, hex socket, or driver bit for the fasteners
that you supply.
3.175 mm (1/8
inch)
4 User-supplied toggle bolts (if not using screws into a framing mem-
ber)
#10 (4.762 mm,
3/16 inch)
4 User-supplied structural screws such as decking screws (f not using
toggle bolts into drywall)
M5 x 4 2 Stainless steel shoulder bolts and washers (supplied with the dock-
ing station.
Refer to Figure 3-14 for dimensions and fastener placement.
