196 LD-250 Platform User's Guide 20472-000 Rev B
10.3 Docking Station Specifications
10.3 Docking Station Specifications
Description Specification
Current 8 A
Circuit protection Thermal circuit breaker rated at 10A (IEC) or 15A (UL).
Contacts 2
Voltage 100-240 VAC, 50/60 Hz
Power consumption 800 W
Short circuit current rating (SCCR) Fuse: 1500 A, Circuit Breaker 2000 A
Humidity 5% to 95% non-condensing
Temperature 5 to 40°C (41 to 104°F)
Dimensions - WxDxH
with Floor plate
349 x 369 x 315 mm [13.75 x 14.5 x 12.4 inches]
495 x 495.5 x 317 mm [16 x 19.5 x 12.5 inches]
Weight 8.2 kg (18 lbs)
Mounting Wall bracket, directly to floor, or on floor with floor plate
Indicators Power on - blue
Charging - amber
Connector For manual charging of spare batteries
NOTE: The LD-250 can also use older model docking stations that use a 10 A
time-lag fuse.
