A-8 MicroHAWK Engine Integration Guide
Electrical Specifications
Ribbon Cable / ZIF Connector Pin Assignments
See Electrical Specifications in Integration for additional electrical information.
Pin Name Direction Description Specifications Notes
1 3V3 SNVS Output 3.3V IO Power 3.3V +/- xx% @ xx mA Max Common with pin 3
2 LED_LINK_ACT Output
Output Indicator
ENET Link and Activity
CPU GPIO xx VDC +/- xx
mA Max
3 3V3 SNVS Output 3.3V IO Power 3.3V +/- xx% @ xx mA Max Common with pin 1
4 LED_TRIG Output
Output Indicator
Trigger
CPU GPIO xx VDC +/- xx
mA Max
5 GND Digital Ground Common with pin(s) 7,36,38
6 SPI_CS1 Output
7 GND Digital Ground Common with pin(s) 5,36,38
8 SPI_CLK Output Serial Periperhal I/F CLK Use with pin(s) 10,12
9 RESERVED
10 SPI_DATA In/Out Serial Periperhal I/F CLK Use with pin(s) 8,12
11 1.8V Output
12 SPI_CS Output Serial Periperhal I/F CLK Use with pin(s) 8,10
13 1.8V Output
14 OUT_2 Output
15 BEEPER+ Output
16 OUT_1 Output
17 LED_BAD_FAIL Output
Output Indicator
BAD READ/FAIL
CPU GPIO xx VDC +/- xx
mA Max
18 OUT_3 Output
19 TRIGGER Input
20 SHUT_STRB Output
21 INPUT_2 Input
22 BUTTON Input Push Button Input
FW Funtionality of Setup
Button
23 FIFTH_LED Output
Output Indicator
MODE
CPU GPIO xx VDC +/- xx
mA Max
24 I2C3_SDA In/Out I
2
C Interface Data Use with pin 26
25 LED_GOOD_PASS Output
Output Indicator
GOOD READ/PASS
CPU GPIO xx VDC +/- xx
mA Max
26 I2C3_SCL Output I
2
C Interface Clock Use with pin 24
27 INPUT_1 Input
28 OGD2_DN In/Out USB Data - USB 2.0
29 PWM_ILLUM Output
30 OGD2_DP In/Out USB Data + USB 2.0
31 RX_DATA Input Receive DATA
VDD = 3.3V (See DVGPIO I/
O DC Parameters Table)
RS-232C Transceiver
Required
32 VBUS Input
33 TX_DATA Output Transmit DATA
VDD = 3.3V (See DVGPIO I/
O DC Parameters Table)
RS-232C Transceiver
Required
34 RESERVED
35 RESERVED
36 GND Digital Ground Common with pin(s) 5,7,38
37 LED_SPEED Output
38 GND Digital Ground Common with pin(s) 5,7,36
39 ETH_TPI_N
40 +5V Input 5VDC Main Input 5.0 +/- 5% @ 1200mA
Common with pin(s) 42,45
Input Power Dependent on
Ext Config
41 ETH_TPI_P
42 +5V Input 5VDC Main Input 5.0 +/- 5% @ 1200mA
Common with pin(s) 40,45
nput Power Dependent on
Ext Config
43 ETH_TPO_N
44 +5V Input 5VDC Main Input 5.0 +/- 5% @1200mA
Common with pin(s) 40,42
nput Power Dependent on
Ext Config
45 ETH_TPO_P
