MicroHAWK Engine Integration Guide 1-17
Quick Start
MicroHAWK Engine and ESP Quick Start
Step 1 — Check Hardware and Connect the System
Item Description Part Number
1 MicroHAWK Engine
7AXY-YZZZ-LPPP
2 Micro-USB Type B Plug to USB Type A Plug, 6 ft. (High Speed USB 2.0) 61-9000034-01
3
Ferrite Core Snap-On Kit for USB Cable (for Class B Emissions; not shown) 98-9000035-01
4 Power Supply, 100-240VAC, +24VDC, M12 12-pin Socket (not shown) 97-000012-01
MicroHAWK Engine – USB Standalone Configuration
To Host USB Type A
Plug
Micro-USB
Type B Plug
1
2
