3-2 MicroHAWK Engine Integration Guide

MicroHAWK Engine Hardware at a Glance

Item Description

1 Camera Imager

2 White Illumination

3 Red Illumination

4 USB, Micro B, Receptacle

5 FPC, 45-Pin, .3 mm Pitch

6 Green Flash (Good Read)

7 Blue Targeting

8 M2 Mounting

9 Keying Location
