Omron NX-EIC202 User Manual

9 Setting Up Slave Terminals
9 - 48
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
 Changing and Registering Tag Sets
11 The following dialog box will be displayed when the tags in the Edit Tags Dialog Box are regis-
tered directly as tag sets.
12 If an input tag has already been registered in an input tag set, and you want to change its regis-
tration to a different input tag set, it is necessary to delete the tag from the tag set in which it was
originally registered.
Open the Edit Device Parameters Dialog Box, select the tag set containing the tag that you want
to delete, and click the Delete button in the Edit Tag Dialog Box. (If there are other tags regis-
tered in that tag set, it is possible to delete just one tag by selecting the tag that you want to
delete in the Edit Tag Set Dialog Box and clicking the button.)

Omron NX-EIC202 Specifications

General

Brand	Omron
Model	NX-EIC202
Category	Controller
Language	English
