Oracle Netra SPARC T4-1B User Manual

Preparing for Service 55
Related Information
■ “Find the Server Module Serial Number” on page 55
■ “Locate the Server Module” on page 56
▼ Find the Server Module Serial Number
Note – To obtain support for your server module, you need the serial number of the
Sun Netra 6000 modular system in which the server module is located, not the serial
number of the server module. See “Find the Modular System Chassis Serial Number”
on page 54.
The serial number of the server module is located on a sticker on the RFID tag that is
mounted in the center of the front panel. However, this label is not present on a
server module that has been moved into a new enclosure assembly. You also can type
the Oracle ILOM show /SYS command to display the number.
● Access the Oracle ILOM CLI and type.
-> show /SYS
/SYS
Targets:
MB
MB_ENV
HDD0
<...>
<...>
Properties:
type = Host System
ipmi_name = /SYS
keyswitch_state = Normal
product_name = Netra SPARC T4-1B
product_part_number = T4-1B-ATO1-PNET
product_serial_number = 1131NN10F5 <---
product_manufacturer = Oracle Corporation
fault_state = OK
clear_fault_action = (none)
prepare_to_remove_status = NotReady
prepare_to_remove_action = (none)
return_to_service_action = (none)
power_state = On
