118 Netra SPARC T4-1B Server Module Service Manual • June 2012
2. Slide the cover forward until it latches into place (panel 2).
3. Install the server module into the modular system chassis.
See “Install the Server Module Into the Modular System” on page 118.
Related Information
■ “Install the Server Module Into the Modular System” on page 118
■ “Remove the Cover” on page 63
▼ Install the Server Module Into the
Modular System
Caution – Insert a filler panel into an empty modular system slot within 60 seconds
of server module removal to ensure proper chassis cooling.
Caution – Hold the server module firmly with both hands so that you do not drop
it. The server module can weighs as much as 20 pounds (9.0 kg).
1. (If needed) Replace the cover.
See “Replace the Cover” on page 117.
