Servicing the eUSB Drive
The eUSB drive is mounted on the motherboard beneath memory risers CM0/MR0, CM0/MR2,
and CM0/MR3. See “Front Panel Components (Service)” on page 13.
These topics describe how to service the eUSB drive.
■
“Install the eUSB Drive” on page 122
■
“Remove the eUSB Drive” on page 121
Related Information
■
“Detecting and Managing Faults” on page 29
Remove the eUSB Drive
This is a cold-service procedure that can be performed by a customer. Power down the server
completely before performing this procedure.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. Static discharges can cause the components to fail.
1.
Prepare the system for service.
See “Preparing for Service” on page 47.
2.
Remove memory risers CM0/MR0, CM0/MR2 and CM0/MR3.
Servicing the eUSB Drive 121
