I/O Root Complex Connections
I/O Root Complex Connections
SPARC T7 servers use a dedicated chip (IO Hub) to host the PCIe fabric. Each IOH chip has
five root complexes, four are sixteen lanes wide (x16), and one is eight lanes wide (x8). The
root complexes are divided up and assigned to all of the I/O devices in the server. The SPARC
T7-2 server contains two IOH chips. Each IOH chip connects to four of the PCIe slots. The
following table describes the device paths for the server.
The pci@ values reported in the OpenBoot show-devs command output are paths in the I/O root
complex topology.
Device
Name
IOH Root
Complex
(IOS)
Width Root Complex Path Oracle ILOM
Target
PCIeSlot1 0 3 x16
/pci@306/pci@1 /SYS/MB/PCIE1
PCIeSlot2 0 2 x16
/pci@307/pci@1 /SYS/MB/PCIE2
PCIeSlot3 0 1 x8
/pci@300/pci@2 /SYS/MB/PCIE3
PCIeSlot4 0 0 x8
/pci@301/pci@2 /SYS/MB/PCIE4
PCIeSlot5 1 3 x8
/pci@302/pci@2 /SYS/MB/PCIE5
PCIeSlot6 1 0 x8
/pci@303/pci@2 /SYS/MB/PCIE6
PCIeSlot7 1 2 x16
/pci@304/pci@1 /SYS/MB/PCIE7
PCIeSlot8 1 1 x16
/pci@305/pci@1 /SYS/MB/PCIE8
NET0 0 1 x8
/pci@300/pci@1/network@0 /SYS/MB/NET0
NET1 0 1 x8
/pci@300/pci@1/network@0,1 /SYS/MB/NET1
NET2 1 3 x8
/pci@302/pci@1/network@0 /SYS/MB/NET2
NET3 1 3 x8
/pci@302/pci@1/network@0,1 /SYS/MB/NET3
SAS0 0 0 x8
/pci@301/pci@1 /SYS/MB/SASHBA0
SAS1 1 0 x8
/pci@303/pci@1 /SYS/MB/SASHBA1
SPM 0 4 1x of
x4
/pci@309/pci@1 /SYS/MB/SPM
USB 1 4 x4
/pci@308/pci@1 /SYS/MB/USB_CTRL
RCDROM 1 4 x1
/pci@308pci@1/usb@0/hub@1/storage@1/disk@0 /SYS/MB/USB_CTRL
CDROM 1 4 x1
/pci@308/pci@1/usb@0/hub@5/device@4/storage@0 /SYS/MB/USB_CTRL
eUSB 1 4 x1
/pci@308/pci@1/usb@0/hub@1/storage@3 /SYS/MB/USB_CTRL
USB - Rear Top 1 4 x1
/pci@308/pci@1/usb@0/storage@7 /SYS/MB/USB_CTRL
USB - Rear Bottom 1 4 x1
/pci@308/pci@1/usb@0/storage@2 /SYS/MB/USB_CTRL
USB - Front Left 1 4 x1
/pci@308/pci@1/usb@0/hub@4/storage@2 /SYS/MB/USB_CTRL
Servicing PCIe Cards 127
