Oracle SPARC T7-2 User Manual

I/O Root Complex Connections
Device
Name
IOH Root
Complex
(IOS)
Width Root Complex Path Oracle ILOM
Target
USB - Front Right 1 4 x1
/pci@308/pci@1/usb@0/hub@4/storage@1 /SYS/MB/USB_CTRL
HDD0 0 0 x4
/pci@301/pci@1/scsi@0/disk@p0 /SYS/DBP/HDD0
HDD1 0 0 x4
/pci@301/pci@1/scsi@0/disk@p1 /SYS/DBP/HDD1
HDD2 0 0 x4
/pci@301/pci@1/scsi@0/disk@p2 /SYS/DBP/HDD2
HDD3 0 0 x4
/pci@301/pci@1/scsi@0/disk@p3 /SYS/DBP/HDD3
HDD4 1 0 x4
/pci@303/pci@1/scsi@0/disk@p0 /SYS/DBP/HDD4
HDD5 1 0 x4
/pci@303/pci@1/scsi@0/disk@p1 /SYS/DBP/HDD5
NVMe0
Single NMVe card (Slot 1)
Single NVMe Card (Slot 2)
Dual NVMe Switch Cards
0 0 x4
/pci@306/pci@1/pci@0/pci@4/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@4/nvme@0/disk@1
/pci@306/pci@1/pci@0/pci@6/nvme@0/disk@1
NVMe1
Single NMVe card (Slot 1)
Single NVMe Card (Slot 2)
Dual NVMe Switch Cards
0 0 x4
/pci@306/pci@1/pci@0/pci@5/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@5/nvme@0/disk@1
/pci@306/pci@1/pci@0/pci@7/nvme@0/disk@1
NVMe2
Single NMVe card (Slot 1)
Single NVMe Card (Slot 2)
Dual NVMe Switch Cards
1 0 x4
/pci@306/pci@1/pci@0/pci@6/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@6/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@6/nvme@0/disk@1
NVME3
Single NMVe card (Slot 1)
Single NVMe Card (Slot 2)
Dual NVMe Switch Cards
1 0 x4
/pci@306/pci@1/pci@0/pci@7/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@7/nvme@0/disk@1
/pci@307/pci@1/pci@0/pci@7/nvme@0/disk@1
Related Information
■
“Server Block Diagram” on page 25
■
“PCIe Card Configuration” on page 125
■
“Rear Panel Components (Service)” on page 15
■
“Remove a PCIe Card or Filler” on page 129
■
“Install a PCIe Card or Filler” on page 131
128 SPARC T7-2 Server Service Manual • July 2019
