Interpreting LEDs
Component Oracle ILOM Target Service Procedure
/SYS/MB/CM1/CMP/MR1
/SYS/MB/CM1/CMP/MR2
/SYS/MB/CM1/CMP/MR3
Motherboard
/SYS/MB
“Servicing the
Motherboard” on page 147
PCIe card
/SYS/MB/PCIE1
/SYS/MB/PCIE2
/SYS/MB/PCIE3
/SYS/MB/PCIE4
/SYS/MB/PCIE5
/SYS/MB/PCIE6
/SYS/MB/PCIE7
/SYS/MB/PCIE8
“Servicing PCIe
Cards” on page 125
Power supplies
/SYS/PS0 (outer)
/SYS/PS1 (inner)
“Servicing Power
Supplies” on page 85
PS backplane and cover
/SYS/PDB
“Servicing the PS
Backplane” on page 165
SP
/SYS/MB/SPM
“Servicing the SPM” on page 135
Related Information
■
“Log In to Oracle ILOM (Service)” on page 30
■
“Identify Faulted Components” on page 31
■
“Identify Disabled Components” on page 33
Interpreting LEDs
Use these steps to determine if an LED indicates that a component has failed.
Step Description Links
1. Check the LEDs on the front and rear of the server. ■ “Front Panel Controls and
LEDs” on page 36
