Install the PS Backplane
9.
Lift the PS backplane out of the chassis.
a.
Slide the PS backplane back towards the power supplies to remove the PS
backplane mount from underneath the motherboard.
b.
Tilt the PS backplane to remove it from the power supply shroud.
c.
Disconnect the AC cables from the PS backplane.
Tilt the PS backplane to access the cable connectors.
10.
Install a new PS backplane.
See “Install the PS Backplane” on page 167.
Related Information
■
“Install the PS Backplane” on page 167.
Install the PS Backplane
This is a cold-service procedure that must be performed by qualified service personnel. Power
down the server completely before performing this procedure.
Caution - This procedure requires that you handle components that are sensitive to ESD which
can cause server components to fail.
1.
Unpack the replacement PS backplane and place it on an antistatic mat.
2.
Hold the PS backplane at the end of the power supply cage at an angle, and
connect the AC cables to the AC connectors on the PS backplane.
Ensure that each AC cable is connected to the appropriate connector. You must connect the AC
cable on the right to the AC connector on the right, and connect the AC cable on the left to the
AC connector on the left.
3.
Insert the PS backplane into position (panel 1).
Servicing the PS Backplane 167
