Identify Disabled Components
Component Names Displayed by Diagnostic
Software
Use the information in this table to identify the name of a component that requires service.
Component Oracle ILOM Target Service Procedure
Battery
/SYS/MB/BAT
“Servicing the Battery” on page 117
DIMMs
/SYS/MB/CMn/CMP/MRn/BOBn/CHn/D0
“Servicing Memory Risers and
DIMMs” on page 91
Drive backplane
/SYS/DBP
“Servicing the Drive
Backplane” on page 159
Drives
/SYS/DBP/HDD0 (bottom)
/SYS/DBP/HDD1
/SYS/DBP/HDD2
/SYS/DBP/HDD3
/SYS/DBP/HDD4
/SYS/DBP/HDD5 (top)
“Servicing Drives” on page 65
DVD drive
/SYS/DBP/DVD
“Servicing the DVD
Drive” on page 113
Fan board
/SYS/FANBD
“Servicing the Fan
Board” on page 141
Fan modules As viewed from front of server:
/SYS/FANBD/F0 (left front)
/SYS/FANBD/F1 (center front)
/SYS/FANBD/F2 (right front)
/SYS/FANBD/F3 (left rear)
/SYS/FANBD/F4 (center rear)
/SYS/FANBD/F5 (right rear)
“Servicing Fan
Modules” on page 77
Memory risers
/SYS/MB/CM0/CMP/MR0
/SYS/MB/CM0/CMP/MR1
/SYS/MB/CM0/CMP/MR2
/SYS/MB/CM0/CMP/MR3
/SYS/MB/CM1/CMP/MR0
“Servicing Memory Risers and
DIMMs” on page 91
