Install a PCIe Card or Filler
7.
Rotate the crossbar to an upright position (panel 1).
8.
Carefully remove the PCIe card or filler from the card slot (panel 2).
9.
Replace with another PCIe card or filler before the server is connected to power
again.
See “Install a PCIe Card or Filler” on page 131.
Related Information
■
“Install a PCIe Card or Filler” on page 131
Install a PCIe Card or Filler
Caution - This procedure requires that you handle components that are sensitive to ESD which
can cause server components to fail.
1.
Take the necessary ESD precautions.
See “Prevent ESD Damage” on page 57.
2.
Ensure that the server is powered off and all power cords are disconnected from
the server power supplies.
See “Removing Power From the Server” on page 53.
3.
Determine which slot to install the PCIe card in.
If you are not replacing an existing PCIe card and need information about deciding which slot
to install the card in, see “PCIe Card Configuration” on page 125.
4.
Disengage the PCIe card slot crossbar from its locked position by pulling it
toward the interior of the chassis.
The crossbar might already be disengaged if you removed a PCIe card or filler from that slot.
5.
Install the PCIe card or filler into the card slot and return the crossbar to its
closed and locked position.
Servicing PCIe Cards 131
